ULTRASUB
The ULTRA SUB is a high performance subwoofer designed for low-frequency extension in high-demanding touring and install applications, indoors and outdoors, housing two long excursion best-in-class 19″ drivers built into a bandpass horn cabinet design.
The 19 inch cone size is the ideal balance between traditional high-speed 18” and the slower 21” and inherits the best characteristics of the two sizes.
The paper cone is made of specially developed composite pulp and added with special fibers; the 116.5mm voice coil is made of specially customized voice coil wire; coupled with the high-efficiency magnetic circuit design, all those contribute excellent reproduction quality and extreme sound pressure.
The enclosure is provided with power connections on front and back panels for easy deployment in cardioid configuration. Up to 16 pcs ULTRA SUB speaker can be flown on a single fly-bar.
The cabinets are constructed from high quality plywood with weather protected polyurea coating.
| Model No. | ULTRA 12W | ULTRA 12F | ULTRA SUB |
|---|---|---|---|
| Frequency Response | 40Hz – 18KHz (±3dB) 35Hz – 20KHz (−10dB) |
30Hz – 100Hz (±3dB) 25Hz – 120Hz (−10dB) |
|
| Sensitivity (@1w/1m) | Hi: 113dB, Mid: 107dB, LowL: 98dB, LowR: 98dB | Hi: 114dB, Mid: 107dB, LowL: 98dB, LowR: 98dB | 108dB |
| Nominal Impedance | Hi: 16Ω, Mid: 8Ω, LowL: 8Ω, LowR: 8Ω | 4Ω | |
| Power Rating (AES) | Hi: 180W, Mid: 480W, LowL: 500W, LowR: 500W | 2800W | |
| LF Driver | LowL: 1 × 12″ (75mm voice coil) LowR: 1 × 12″ (75mm voice coil) |
2 × 19″ (115mm voice coil) ferrite | |
| MF Driver | Mid: 4 × 6.5″ (38mm voice coil) | – | |
| HF Driver | Hi: 2 × 3″ (1.4″ exit) neodymium (75mm voice coil) | – | |
| Nominal Dispersion | H: 110° V: 10° | H: 70° V: 10° | – |
| Rigging | 3 rigging points, from 0° to 10°, adjustable | 4 rigging points | |
| Max SPL |
Hi: 136dB, 142dB Peak Mid: 134dB, 140dB Peak LowL: 125dB, 131dB Peak LowR: 125dB, 131dB Peak |
Hi: 137dB, 143dB Peak Mid: 134dB, 140dB Peak LowL: 125dB, 131dB Peak LowR: 125dB, 131dB Peak |
142dB SPL, 148dB SPL Peak |
| Weight | 71kg | 130kg | |
| Dimensions (HxWxD) | 361 × 1180 × 540(mm) | 620 × 1180 × 920(mm) | |
| Connector | LK8 × 2 | 2 × Neutrik NL4MP | |
| Connection | LowL: A+B−, LowR: C+D−, Mid: E+F−, Hi: G+H− | 1+1− | |
| Enclosure | 18mm multilayers birch plywood | 18mm multilayers birch plywood | |
| Finishing | Black polyurethane paint | Black polyurethane paint | |
| Grille | Black steel grille with acoustic foam | Black steel grille with acoustic foam | |
