| Model No. | CS_SP | CS_7P | CS_9P |
|---|---|---|---|
| Frequency Res. | 110Hz~16KHz(3x8B) 96Hz~20KHz(-10dB) |
100Hz-20KHz(3x8B) 80Hz-20KHz(-10dB) |
80Hz~20KHz(3x8B) 70Hz~20KHz(-10dB) |
| Sensitivity(@1w/1m) | 83dB | 94dB | 95dB |
| Impedance | 160 | 80 | 80 |
| Power Rating(AES) | 100W | 200W | 400W |
| LF Driver | 1x5" (44mm voice coil), Ferrite | 1x7" (50mm voice coil), Ferrite | 1*9" (65mm voice coil), Ferrite |
| HF Driver | 1*1" (25mm voice coil) compression driver, Neodymium | 1*1" (38mm voice coil) compression driver, Neodymium | 1*1" (38mm voice coil) compression driver, Neodymium |
| Dispersion | 110'x 110" | 110'x 110" | 110'x 110" |
| Riggings | M6×3LM10 pole mount | M6×3LM10 pole mount | M6×3LM10 pole mount |
| Max SPL | 115dB:121dB peak | 117dB:123dB peak | 121dB:127dB peak |
| Dimension (HxWxD) | 6 x 6 x 6 (in) | 7 x 7 x 7 (in) | 9 x 9 x 9 (in) |
| Net Weight | 7 lbs | 14 lbs | 22 lbs |
| Connector | 2-Neutrik NL4MP:2+2-point screw terminals | 2-Neutrik NL4MP:2+2-point screw terminals | 2-Neutrik NL4MP:2+2-point screw terminals |
| Connection | 1+1- | 1+1- | 1+1- |
| Endosure | 9mm multilayer plywood | 9mm multilayer plywood | 9mm multilayer plywood |
| Finishing | Water-based paint | Water-based paint | Water-based paint |
| Grille | Steel mesh + acoustic transparent cloth | Steel mesh + acoustic transparent cloth | Steel mesh + acoustic transparent cloth |
